  Welcome to Saratronics!

  Since 2007, Saratronics offers a selection of high quality educational electronic kits; assembled modules and  spare parts  on the web.
  All technical documents; schematics; softwares; illustrations and sound samples can be freely downloaded from our website for non-commercial use only.
  Saratronics also offers custom design service (modifications to any of our existing electronic kits or design for new projects). Contact us for more information.
  We  only sell  these kits to training organizations; universities; colleges; schools; students and hobbyists.

  ALL KITS AND MODULES :

  SARA-001 Rev.1  (our first kit, available since march 2007)

  Powerful programmable Complex Stereo Sound Generator for Sound Effects and Music Synthesis.
  Based around the unknown SAA1099P chip, offers 6 frequency generators (8 octaves per generator and 256 tones per octave); 2 noise generators; 6 noise/frequency mixers;
  12 amplitude controllers; 2 envelope generators; Dual 6 channels mixers/current sink analog output stages.
  The top quality PCB (manufactured in USA) measures only 2" x 2" (5,1cm x 5,1cm) and the KIT work with a single +5VDC power supply.
  Need any external CPU or microcontroller to generate sound (this module is not standalone).

  SARA-001 Rev.1 in KIT FORM (Order Code : SARA-001 Rev.1 KIT FORM  Price : 15 €)



  SARA-001 Rev.1 ASSEMBLED AND TESTED (Order Code : SARA-001 Rev.1 ASSEMBLED  Price : 20 €)



  All documents (pictures; schematics ;datasheets and program samples for use with a Basic Stamp II) can be downloaded "HERE" in a single ZIP file.

  SARA-001 Rev.2  (NEW, available now ! )

  Powerful and versatile programmable Complex Stereo Sound Generator for Sound Effects and Music Synthesis with its own microcontroller (PIC16F628A) included on board.
  Based around the unknown SAA1099P chip, offers 6 frequency generators (8 octaves per generator and 256 tones per octave); 2 noise generators; 6 noise/frequency mixers;
  12 amplitude controllers; 2 envelope generators; Dual 6 channels mixers/current sink analog output stages.
  The top quality PCB (manufactured in USA) measures only 2" x 2" (5,1cm x 5,1cm) and the KIT work with a single +9VDC power supply (+5VDC regulator on board).
  The versatility of this kit offers tousands and tousands of sounds and configurations. The possibility are endless.


  SARA-001 Rev.2 in KIT FORM (Order Code : SARA-001 Rev.2 KIT FORM Software 001   Price : 20 €)
  (The basic configuration can generate a wide variety of sirens sounds : Programmed PIC16F628A-001 + KEYPAD + Potentiometer + Capacitor + Resistors)



   SARA-001 Rev.2 ASSEMBLED AND TESTED (Order Code : SARA-001-Rev.2  ASSEMBLED Software 001  Price : 25 €)
  (The basic configuration can generate a wide variety of sirens sounds : Programmed PIC16F628A-001 + KEYPAD + Potentiometer + Capacitor + Resistors)



  All documents (pictures; schematics ; datasheets and programs) can be downloaded "HERE" in a single ZIP file.  Few SIRENS Sound Samples can be downloaded "HERE" in a single ZIP file

  SARA-002 Rev.1 (available since march 2008)

  Complex Sound Generator KIT built around the SN76477 chip. Available  in kit form (without PCB) and work with a single +9VDC power supply or battery.
  Can be easily modified or expanded adding new features.

  Main Features :

  1 SLF (Super Low Frequency Oscillator but will operate up to 20 KHz)
  1 VCO (Voltage Controlled Oscillator)
  1 NOISE GENERATOR(Pseudo-Random white noise)
  1 NOISE FILTER (-3dB variable band-width low-pass filter)
  1 MIXER (The mixer logics selects one or a combination of the inputs from the generators)
  1 ATTACK/DECAY CIRCUITRY (alters the rise and fall times of the envelope)
  1 VCA (The dynamic output range is limited to 2,5 volts peak to peak before clipping occurs)

   SARA-002 Rev.1 in KIT FORM  (Order Code : SARA-002 Rev.1 KIT FORM  Price :  30 €)



   All documents (picture; schematic and datasheet  ) can be downloaded "HERE" in a single ZIP file.



  ELECTRONIC COMPONENTS - PCB - SPARE PARTS - ACCESSORIES :

  SAA1099P   Programmable Stereo Complex Sound Generator   (Order Code : SAA1099P  Price : 8,50 €)

  SN76477   Complex Sound Generator   (Order Code : SN76477  Price : 11,00 €)

  PT2399    Echo Processor   (Order Code : PT2399  Price : 2,50 €)

  HT8950    Voice/Sound Modulator  (Order Code : HT8950  Price : 3,50 €)

  PIC16F628A  Blank new Microcontroller  (Order Code : PIC16F628A  Price : 2,50 €)

  PIC16F628A  Programmed with 001.HEX (SIRENS)   (Order Code : PIC16F628A-001  Price : 4,50 €)

  PIC16F628A  Programmed with 002.HEX (PERCUSSIONS)   (Order Code : PIC16F628A-002  Price : 4,50 €)

  OSC-8MHz    High Precision 8MHz Oscillator in metal can    (Order Code : OSC-8MHZ  Price : 1,80 €)

   74HC595     High Speed CMOS Shift Register                     (Order Code : 74HC595  Price : 0,80 €)

  CA3080E     Transconductance OP-AMP                            (Order Code : CA3080E  Price : 2,00 €)

   LM358N     Dual single Power Supply OP-AMPs                (Order Code : LM358N  Price : 0,50 €)

   LM555CN   Universal single Timer                                     (Order Code : LM555CN  Price : 0,50 €)

   NE556N   Universal dual Timer                                           (Order Code : NE556N  Price : 0,80 €)

   TMS5220CNL   Universal Speech Synthesizer                  (Order Code : TMS5220CNL  Price : 7,50 €)

  TMS9929ANL  Video Display Processor                 (Order Code : TMS9929ANL  Price : 9,50 €)

  MCM4517P15  Video SRAM                                                (Order Code : MCM4517P15  Price :  2,00 €)

  TC5501P  SRAM  (256x4)                                                   (Order Code : TC5501P  Price :  5,00 €)

  PCD5101P  SRAM  (256x4)                                                  (Order Code : PCD5101P  Price :  4,50 €)

  2SC945  Universal NPN Transistor (pack of 10)                (Order Code : 2SC945  Price : 1,50 €)

  2SA733  Universal PNP Transistor (pack of 10)                (Order Code : 2SA733  Price : 1,50 €)

  2SK30A  N-CHANNEL FET (pack of 10)                               (Order Code : 2SK30A  Price : 2,00 €)

  7805 +5VDC TO-220 Voltage Regulator                           (Order Code : 7805-TO220  Price : 0,80 €)

  1N4729A  3,6V Zener Diode                                              (Order Code : 1N4729A  Price : 1,00 €)

  10uH Self                                                                           (Order Code : 10uH-SELF  Price : 0 ,80 €)

  10nF Mylar Capacitor (pack of 10)                                    (Order Code : 10nF  Price : 1,50 €)

  0,1uF 5% Polystyrene Capacitor (pack of 10)                 (Order Code : 100nF-5%  Price : 1,90 €)

  1uF  Electrolytic Radial Capacitor (pack of 10)                 (Order Code : 1uF  Price : 1,90 €)

  10uF  Electrolytic Radial Capacitor (pack of 10)            (Order Code : 10uF  Price : 2,00 €)

  150 Ohms 5% Carbon Resistor (pack of 10)                (Order Code : 150R-5%  Price : 0,90 €)

  1K Ohms 5% Carbon Resistor (pack of 10)                  (Order Code : 1K-5%  Price : 0,90 €)

  4,7K Ohms 5% Carbon Resistor (pack of 10)               (Order Code : 4,7K-5%  Price : 0,90 €)

  10K Ohms 5% Carbon Resistor (pack of 10)                 (Order Code : 10K-5%  Price : 0,90 €)

   10K Ohms Linear Carbon Potentiometer with assorted k nob     (Order Code : 10KB+KNOB  Price : 1,20 €)

   50K Ohms Linear Carbon Potentiometer with assorted knob      (Order Code : 50KB+KNOB  Price : 1,20 €)

   100K Ohms Linear Carbon Potentiometer with  assorted knob    (Order Code : 100KB+KNOB  Price : 1,20 €)

   1M Ohms Linear Carbon Potentiometer with  assorted knob        (Order Code : 1MB+KNOB  Price : 1,20 €)

   8 pins DIL Socket                                                                            (Order Code : SOCKET8  Price : 0 ,20 €)

  14  pins DIL Socket                                                                           (Order Code : SOCKET14  Price : 0 ,30 €)

  16 pins DIL Socket                                                                           (Order Code : SOCKET16  Price : 0 ,30 €)

  18 pins DIL Socket                                                                           (Order Code : SOCKET18  Price : 0 ,40 €)

  28 pins DIL Socket                                                                           (Order Code : SOCKET28  Price : 0 ,50 €)

  Normaly OFF PushButton (ON when pushed)                                   (Order Code : PUSHBUTTON  Price : 1 ,20 €)

  Bipolar ON-ON Switch                                                                       (Order Code : SWITCH2P-ON-ON  Price : 1 ,20 €)

  CINCH Connector PCB mount (pack of 2)                                         (Order Code : CINCH  Price : 1 ,20 €)

  5 Pins DIN MIDI PCB mount                                                              (Order Code : MIDI5-PCB  Price : 1 ,00 €)

  5 Pins DIN MIDI Panel Mount                                                          (Order Code : MIDI5-PANEL  Price : 1 ,20 €)

  PCB Terminal Block (2 Terminals)                                                       (Order Code : BLOCK2T  Price : 0 ,40 €)

  PCB Terminal Block (4 Terminals)                                                       (Order Code : BLOCK4T  Price : 0 ,80 €)

  PCB Terminal Block (6 Terminals)                                                   (Order Code : BLOCK6T  Price : 1,20 €)

  PCB Terminal Block (8 Terminals)                                                     (Order Code : BLOCK2T  Price : 1,60 €)

  PCB 10 Pin Male Header                            (Order Code : HEADER10M  Price : 0,40 €)

  10 Pin Female Header                               (Order Code : HEADER10F  Price : 0,60 €)

  12 Keys KEYPAD (0-9; * and #)               (Order Code : KEYPAD  Price : 4 ,50 €)

  SARA-001 Rev.1  Top quality PCB          (Order Code : PCB1  Price : 6,00 €)

  SARA-001 Rev.2  Top quality PCB          (Order Code : PCB2  Price : 6 ,00 €)

  12,5mm M3 Round Standoff   (Pack of 4)       (Order Code : M3 Standoff  Price : 1 ,20 €)

  Stereo CINCH audio cable (1,5m)      (Order Code : Stereo audio cable  Price : 2,5 0 €)
